| Product Description | ||||
| Resin Identification | High rigidity, excellent chemical resistance, abrasion resistance, food contact grade, autoclave-sterilised, fatigue-resistant, heat-sterilised, radiation-sterilised, steam-resistant, biocompatible, steam-sterilised | |||
| Color | Natural or typical colour | |||
| Main applications | Electrical components, electronic components, robotic applications, bearing sleeves, bearing flanges, connectors, water pump accessories, seals, surgical instruments | |||
| Processing Method | Injection Molding | |||
| Typical Properties | Test Method | Test Condition | Value | Unit |
| Physical Properties | ||||
| Density | DIN EN ISO 1183 | 23℃ | 1.32 | g/cm³ |
| Melt Flow Rate | DIN EN ISO 1133 | 400℃/5kg | 65 | g/10min |
| Shrinkage | GB 15585 | 1.4-1.6 | % | |
| Mechanical Properties | ||||
| Tensile Strength | DIN EN ISO 527 | 50mm/min | 100 | MPa |
| Tensile modulus | 4000 | MPa | ||
| Elongation at Break | 15 | % | ||
| Flexural Strength | DIN EN ISO 178 | 2mm/min | 134 | MPa |
| Flexural Modulus | 3900 | MPa | ||
| Cantilever Beam Unnotched Impact Strength |
DIN EN ISO180 | 4mm,23℃ | NB | KJ/M² |
| Izod Notched Impact Strength | DIN EN ISO 180 | 4mm,23℃ | 5.4 | KJ/M² |
| Thermal Performance | ||||
| Heat Deformation Temperature | DIN EN ISO 75 | 1.8MPa, unannealed | 155 | ℃ |
| Heat Deformation Temperature | DIN EN ISO 75 | 0.45MPa, unannealed | 210 | ℃ |
| Melting temperature | DIN EN ISO 11357 | 340 | ℃ | |
| linear expansion coefficient | DIN EN ISO 11359 | Flowing, below Tg | 8.00E+00 | μm/m/℃ |
| linear expansion coefficient | DIN EN ISO 11359 | Flowing, above Tg | 8.00E+00 | μm/m/℃ |
| Thermal Performance | ||||
| Surface Resistance | IEC 60093 | 23℃ | 1.00E+13 | Ω.CM |
| Volume Resistance | IEC 60093 | 23℃ | 1.00E+15 | Ω.CM |
| insulation strength | IEC 60243 | 2.0mm | 19 | KV/mm |
| dielectric strength | IEC 62631-2-1 | 23℃ 1 KHz | 2.8 | |
| dissipation factor | IEC 62631-2-1 | 23℃ 1 MHz | 0.003 | |
| CTI | IEC 60112 | 200 | V | |
| Flame-retardant properties | ||||
| Flame-retardant properties | UL94 | 0.3mm | V0 | |
| Flame-retardant properties | UL94 | 0.5mm | V0 | |
| Flame-retardant properties | UL94 | 1mm | V0 | |
| Flame-retardant properties | UL94 | 1.5mm | V0 | |
| Glow wire flammability index | IEC60695-2-12 | 0.75mm | 960 | ℃ |
| Glow wire flammability index | IEC60695-2-12 | 1.5mm | 960 | ℃ |
| Glow wire flammability index | IEC60695-2-12 | 3mm | 960 | ℃ |
| Glow wire flammability index | IEC60695-2-13 | 0.75mm | 850 | ℃ |
| Glow wire flammability index | IEC60695-2-13 | 1.5mm | 850 | ℃ |
| Glow wire flammability index | IEC60695-2-13 | 3mm | 960 | ℃ |
Note:
(1) Data represents typical values and is provided solely for customer reference. It does not constitute a guarantee of minimum or maximum quality standards, nor any other form of assurance.
(2) Performance may vary across different colours.
Note:
The data and information herein are based on our current knowledge and experience. Should new knowledge or experience arise in future, we reserve the right to modify the information and data contained herein without prior notice. As usage conditions and applicable laws may vary by location and time, it remains the customer's responsibility to determine whether the products and product information described herein are suitable for their intended use, and to ensure their workplace and product handling methods comply with applicable laws and other governmental regulations. Lisu New Materials assumes no liability or obligation whatsoever in relation to this document, nor does it provide any warranties. All implied warranties regarding the merchantability or fitness for a particular purpose of the products described herein are hereby expressly excluded.
This text contains no warranties of any kind. All implied warranties of merchantability or fitness for a particular purpose are hereby expressly excluded.
| Typical Injection Molding Process | |
| Plastic Drying | |
| Drying Time | 2–4 hours |
| Drying Temperature | 130–150°C |
| Drying Equipment | Hot-air dryer |
| Drying Type | Continuous drying (production process) |
| Injection Molding Process | |
| Nozzle Section | 370~390℃ |
| PlasticsSection | 380~400℃ |
| ConveyingSection | 360~380℃ |
| Maximum Injection Temperature | 450℃ |
| Injection Pressure | 30~70MPa |
| Injection Speed | 30~75mm/s |
| Plasticization PressureVelocity | Pressure: 35–70 MPa Speed: 50–100 mm/s |
| Plasticization Back Pressure | 20~60MPa |
| Recommended Mold Temperature | 170~220℃ |
Disclaimer: The aforementioned injection moulding processes may vary depending on the product geometry, mould design, and injection moulding machine specifications. Specific adjustments should be made according to actual circumstances.
