| Product Description | |
| Resin Identification | The fabric features softness, good flexibility, and a velvety matte effect, with an imitation flocking finish |
| Color | semitransparent |
| Main applications | The company specializes in producing casings for cosmetic products, household appliances, and personal care items, as well as flexible packaging solutions |
| Processing Method | extrusion blow molding/ Injection Molding |
| Typical Properties | Test Method | Test Condition | Value | Unit |
| Physical Properties | ||||
| Density | DIN EN ISO 1183 | 23℃ | 0.93 | g/cm³ |
| Melt Flow Rate | DIN EN ISO 1133 | 230℃/10kg | 45 | g/10min |
| Shrinkage | GB 15585 | 1.4-1.7 | % | |
| Mechanical Properties | ||||
| Tensile Strength | DIN EN ISO 527 | 50mm/min | 12 | MPa |
| Elongation at Break | 600 | % | ||
| Flexural Strength | DIN EN ISO 178 | 2mm/min | 7 | MPa |
| Flexural Modulus | 330 | MPa | ||
| Tensile modulus | ISO 527 | 50mm/min | 360 | MPa |
| Izod Notched Impact Strength | DIN EN ISO 180 | 4mm,23℃ | 65 | KJ/M² |
| Izod Notched Impact Strength | DIN EN ISO 180 | 4mm,-30℃ | NB | KJ/M² |
| Thermal Performance | ||||
| Heat Deformation Temperature | DIN EN ISO 75 | 0.45MPa | 50 | ℃ |
| Vika softens | ISO 306 | 50²C/Hr 10N | 78 | ℃ |
| Melting temperature | ISO11357 | 163 | ℃ | |
Note: (1) The data is a typical value, which is only used as a reference for customer use, and is not used as a guarantee of the lowest or highest value of the quality index or any other purpose. (2) Different color properties may be different.
Note: The data and information in this text is based on our current knowledge and experience. If there is new understanding and experience in the future, the possibility of making changes to the information and data in this text without prior notice is not excluded. Because conditions of use and applicable laws may vary from place to place, it is Customer's responsibility to determine whether the products and product information in this text are appropriate for Customer and to ensure that its premises and manner of handling Products comply with applicable laws and other governmental regulations. Resu Technology assumes no responsibility or liability for the information in this text, nor does it provide any warranty. All implied warranties in this text regarding the merchantability of the product or the fitness for a particular purpose are hereby expressly excluded
| Typical Injection MoldingProcess | |
| Plastic Drying | |
| Drying Time | 2~4h |
| Drying Temperature | 40~60℃ |
| Drying Equipment | Hot-Air Dryer |
| Drying Type | Continuous Drying (Production Process) |
| Injection Molding Process | |
| Nozzle Section | 210~240°C |
| PlasticsSection | 200~250°C |
| ConveyingSection | 180~220°C |
| MaximumInjection Temperature | 280°C |
| Injection Pressure | 40~120MPa |
| Injection Speed | 30~75mm/s |
| Plasticization Pressure Velocity | 65~100MPa,60-85mm/s |
| Plasticization Back Pressure | 10~40MPa |
| Recommended MoldTemperature | 30~50℃ |
Statement: The above injection molding process should be different according to the shape of the product, mold design and injection molding machine specifications and other conditions, and should be adjusted according to the actual situation.
